| Model Number |
RBMB01(L)-SOLAR-DUAL |
| Item Number |
TX-MB-01(L) Dual Solar |
| Type |
Medium Intensity Type A (Day) and Type B (Night) Dual Beacon |
| FAA Classification |
L-865 (Daytime) and L-864 (Nighttime) |
| Power Supply |
Solar power supply (DC) |
| Power Frequency |
DC supply |
| Average Power Consumption |
2.5W or less |
| Solar Panel Power |
25W monocrystalline silicon |
| Battery Type |
Lithium iron phosphate battery (LiFePO4) |
| Battery Capacity |
12.8V 12AH |
| Working Mode |
Flashing (auto day/night switching via photocell) |
| Flash Frequency |
30 times per minute |
| Effective Intensity (Daytime) |
20,000 cd white (Type A, FAA L-865) |
| Effective Intensity (Nighttime) |
2,000 cd red (Type B, FAA L-864) |
| Light Source |
LED (dual) |
| Light Source Lifespan |
200,000 hours or more |
| Emitted Color |
White (day) and Red (night) |
| Shell Material |
Aviation dedicated aluminum alloy |
| Luminous Mirror Material |
Optical PC |
| Vertical Divergence |
3 degrees |
| Horizontal Output |
360 degrees |
| Overall Size (with panel) |
515 x 450 x 350 mm (L x W x H) |
| Installation Size |
Phi 90 mm x 4 x M8 |
| Photocell Stage |
50 / 100 Lux (auto day/night switching) |
| Ambient Temperature |
-40 degrees C to +55 degrees C |
| Relative Humidity |
0% to 95% |
| Protection Grade |
IP68 |
| Wind Load |
240 km/h |
| Weight |
Approximately 6.2 kg |
| Seismic Resistance |
10 to 500Hz, 2G, 10 min/cycle, XYZ 60 minutes per axis |
| Mean Time Between Failure |
200,000 hours or more, MIL-HDBK-217F (25 degrees C) |
| EMC Standards |
Emitted EN55022 (CISPR22) Class A, Harmonic EN61000-3-2 and -3 |
| Operating Altitude |
5500 m or more above sea level |
| Rain Resistance |
Can be exposed to rain in any wind direction |
| Salt Spray |
Can be exposed to salt spray |
| Radiation |
Can be exposed to solar radiation |
